Features
suitable to the 13-pin plug of the trailer (used 8-pins) CAN-BUS data readout trailer reverse lights control LED/bulb lamps support, PWM control trailer LED/bulb lamps support independent rear fog lights control trailer rear fog lights turning-on audio alarm signaling of status by tri-color LED display trailer auto-detection audio alarm signaling by LED display about malfuntion of directions lights on the trailer trailer's turn signal lights damage audio alarm and detection displaying status of switching-on fog light on the trailer displaying status of connection/disconnection of trailer output for enabling of switching off PDC signalization in car OPTION: additionally variants of stitching off PDC signalling using separatelly PDC-OFF modules displaying malfunction of trailers turn lights on car dashboard display panel (for selected cars) automatically deactivation rear PDC sensors when trailer is connected (for selected cars) automatically blocking of switching-on rear fog-light when trailer is connected (for selected cars) blocking of car trunk opening by driver using remote switch if trailer is connected (for selected cars)
Add to compare list Add to selected
MP2S-CAN-G8

Main module (MP2S-CAN) - in contrast to others - reads inputs data from CAN-Bus of car - not from wires to lamps.Thanks to this count of needed connections under installation time is much less than in case of "typical" modules. More over - main cable harness is already connected with socket - this also makes an installation process easier and faster.



MP2S-CAN-G8 use first 8 pins of socket for steering all lamps (include REV light) on trailer. When is required of operate with "full" G13 socket ("permament plus", loading circuit of trailers battery) should be user PowerKit+RelayKit. In this case module also controls when loading circuit of trailer battery should be switched on: only when cars engine operates (more than 10 secs).



MP2S-CAN module supports many of car models present on the European market - but must be configured for concrete type/model of car. It is made by use (optionaly) device Bootloader and software (available for free). Module is equipped with an output for deactivate of parking sensors module (PDC) in car - but for some cars this can be realised "directly".
Note: continious product improvement and electronic components market availability lead MP2S-CAN-XXX MCU (main control unit) to be oferred in a few versions with small changes. However, general module functions depends on a current firmware generation and still the same for each one.



In special cases (when this is required) is possible to make contact-less data reading from CAN-Bus (without "hard" contact - without "phisically integration" with an installation of car) using optionally module MCB-CLICK-CAN.



The kit is equipped with LED-RGY-500 - tri-colour LED indicator which inform about:

  • connecting of the trailer;
  • damaging the directions lights on the trailer;
  • switching-on fog light on the trailer;
  • loading of trailer battery (when is used: PowerKit+RelayKit).

Here are short movies about operate MP2S-CAN.

Product requires to be installed by specialized workshop - read here.

  • Product's EAN code: 5907662621220
Kit contents
  • Main control unit 1 pc
  • Main cable harness with 13-pin socket 1 pc
  • Signal cables harness (to the CAN-Bus) 1 pc
  • Power cable harness 1 pc
  • Information LED indicator (3-colours) 1 pc
  • Mounting set 1 set
  • Screw set 1 set
  • Connections diagram 1 pc
Module main features
CAN-Bus vehicle data readout
LED lights and single filament bulbs support (car)
LED lights and filament bulbs support(trailer)
Trailer/camper connection detection (bulb lamps)
Trailer/camper connection detection (LED lamps)
Ability to control of park sensors module in car
Trailer turn signal lamps failure detection
Trailer reverse light control
Permanent power supply to trailer socket
(possible using PowerKit+RelayKit)
Intelligent charging of trailer battery
(possible using PowerKit+RelayKit)
Alerts & Notifications
Trailer connection notification
Trailer turn signal failure
Trailer/caravan fog lights switching on/off notification
Car rear fog-lights control modes
Trailer fog lights control modes
sequence or direct
Trailer fog light sequential(independent) control
Car rear fog lights cut-off
Features of electric cable harness
Mounted socket on the cable harness
Length of power harness
5,0 m
Length of cable harness to the socket
1,7 m
Length of input signals cable harness
(to CAN-Bus) 5,0 m
Technical data
Power supply voltage
10-18 V
Position lights output power, max
(each of sides) 3 x 5 W
Stop lights output power, max
3 x 21 W
Turn signal output power, max
(each of sides) 21+10 W
Fog-light output power, max
21 W
Reverse lights output power, max
21 W
Parking sensors output load capacity, max
0,5 A
Kit equipment
Complete bundle of towbar with installation accessories
Filter by car

Select car type, make and model to find available manuals.

clear form

Manuals
  • MP2S-CAN-G8 (v5) Audi A4 [B8] (2007-2015)

    Audi / A4 / B8/8K [restyling] (2011-2015)

    Audi / A4 / B8/8K (2007-2011)

  • MP2S-CAN-G8 (v5) prg34 KIA/Hyundai set1

    Kia / Sportage / [NQ5] (2021-2023)

    Kia / Sorento / [MQ4] (2020-2023)

    Hyundai / Tucson / [NX4] (2020-2023)

    Hyundai / Ioniq 5 / [NE] (2021-2023)

  • MP2S-CAN-G8 (v5) Audi Q5 [8R] (2008-2016)

    Audi / Q5 / 8R [restyling] (2012-2016)

    Audi / Q5 / 8R (2008-2012)

  • MP2S-CAN-G8 (v5) BMW 5 [E60/61]

    BMW / 5 Series / E60/E61 (2003-2007)

    BMW / 5 Series / E60/E61 [restyling] (2007-2010)

  • MP2S-CAN-G8 (v5) BMW set3

    BMW / 1 Series / F20/F21 (2011-2014)

    BMW / 3 Series / F30/F31/F34 (2012-2014)

  • MP2S-CAN-G8 (v5) prg26 BMW (group1)

    BMW / 1 Series / E81/E82/E87/E88 [restyling] (2007-2012)

    BMW / 1 Series / E87 (2004-2007)

    BMW / 3 Series / E90/E91/E92/E93 [restyling] (2008-2013)

    BMW / 3 Series / E90/E91/E92/E93 (2004-2010)

    BMW / X1 / E84 (2009-2012)

    BMW / X1 / E84 [restyling] (2012-2015)

  • MP2S-CAN-G8 (v5) Mercedes C-Class [W205]

    Mercedes-Benz / C-Class / W205/S205/C205 (2014-2018)

    Mercedes-Benz / C-Class / W205/S205/C205 [restyling] (2018-2021)

  • MP2S-CAN-G13 (v5) MERCEDES set1

    Mercedes-Benz / A-Class / W176 (2012-2018)

    Mercedes-Benz / B-Class / W246 (2011-2015)

    Mercedes-Benz / B-Class / W246 [restyling] (2014-2019)

    Mercedes-Benz / CLA-Class / C117 (2013-2019)

    Mercedes-Benz / GLA-Class / X156 (2014-2020)

  • MP2S-CAN-G8 (v5) prg93 OPEL (group1)

    Opel / Astra / J (2009-2012)

    Opel / Astra / J [restyling] (2011-2020)

    Opel / Insignia / A (2008-2014)

    Opel / Insignia / A [restyling] (2013-2017)

    Opel / Meriva / II (2010-2014)

    Opel / Mokka / I (2012-2015)

    Opel / Cascada / I (2013-2019)

    Opel / Corsa / E (2014-2019)

  • MP2S-CAN-G8 (v5) prg11 VW-Group (group1)

    Audi / A3 / 8P (2003-2005) [gen.II also Sportback]

    Audi / A3 / 8P/8PA [restyling] (2004-2008) [gen.II also Sportback]

    Audi / A3 / 8P/8PA [2 restyling] (2008-2013) [gen.II also Sportback]

    Audi / Q3 / 8U (2011-2014)

    Audi / Q3 / 8U [restyling] (2014-2018)

    SEAT / Alhambra / II (2010-2015)

    SEAT / Altea / I (2004-2009) [also XL]

    SEAT / Altea / I [restyling] (2009-2015) [also XL]

    SEAT / Leon / II [restyling] (2005-2012)

    SEAT / Toledo / III (2004-2009)

    Skoda / Octavia / II (2004-2008)

    Skoda / Octavia / II [restyling] (2008-2013)

    Skoda / Superb / II (2008-2013)

    Skoda / Superb / II [restyling] (2013-2015)

    Volkswagen / Golf / V (2003-2008) [also PLUS]

    Skoda / Yeti / I (2009-2014)

    Skoda / Yeti / I [restyling] (2013-17)

    Volkswagen / Golf / VI (2008-2016)

    Volkswagen / Eos / I (2006-2010)

    Volkswagen / Eos / I [restyling] (2010-2015)

    Volkswagen / Jetta / V (2005-2010)

    Volkswagen / Jetta / VI (2011-2014)

    Volkswagen / Passat / B6 (2005-2010)

    Volkswagen / Passat / B7 (2010-2014)

    Volkswagen / Passat CC / I (2008-2011)

    Volkswagen / Tiguan / I (2007-2011)

    Volkswagen / Tiguan / I [restyling] (2011-2016)

    Volkswagen / Touran / I (2010-2015)

    Volkswagen / Sharan / II (2010-2015)

    Volkswagen / Passat CC / I [restyling] (2012-2016)

    Volkswagen / Touran / I (2003-2007)

    Volkswagen / Touran / I [restyling] (2006-2010)
