Module with standard functionality (WH2Q-S) with 13-pin's socket (G13). Kit contains all accessories for connection of module to the car's electric system - and socket G13. Like whole series - this module have integrated all-in-one socket which makes an installation easier.
WH2Q-S module is a successor of canceled module WH2(D)S and takes over all it advantages and functions.
Also installation/connection diagrams are equivalet 1:1 in terms of colors of wires, plugs and connections.
Module have standard functionality, this mean that above basics functions it make possible eg.:
- possibility of switch-off the control unit of parking sensors (PDC);
- sequence switching-off the fog light (54G) on car when it (54G) is still switch-on on trailer;
- signalling of damaged the directions lights on the trailer by buzzer's acoustic signal.
To the module can be connected (optionally) LED-RGY-500 - tri-colour LED indicator which inform about:
- connecting of the trailer;
- damaging the directions lights on the trailer;
- switching-on fog light on the trailer;
- loading of trailer battery (when is used: ICM).
This set can be supplemented with ICM module (intelligent charging module) which is recommended eg. for caravans. ICM module protects car battery because allow to load caravan battery only when car egine is working.
NOTE: If ICM module will not be used then circuit of load caravans battery should be equipped with necessary elements - by own. Sample diagram of these (optional) connections is in basic documentation.
Exclusive distributor of WH2Q series is:
Product requires to be installed by specialized workshop - read here.
- Product's EAN code: 5907662621015
- Main control unit 1 pc
- Integrated wire harness (all-in-1-plug) 1 pc
- Socket G13 1 pc
- Mounting set 1 set
- Screw set 1 set
- Installation manual 1 pc
