IMPORTANT: Product is discontinued and its functional successor is newer (digital) kit: WH3Q-S-G7.
MP2S module is basic module for steering of trailer lights, which provide "copying" of lights from rear of car to the trailer and use sequential method for steering of the fog-light. This is complete kit which include all wires and socket G7. Additionally this module have an output which give a possibility deactivation of main unit controlling of rear parking sensors.
Important is, that MP2S properly working with lamps based on filament bulb or on LED in car. More over - also properly working with PWM steering of lamps in car (when by one wire are controlled two lights - eg. "STOP light" and "tail light").
NOTE: Please remember, that G7 not include circuit for REV light. For example in Poland it can be used only with "lightweight trailer" (gross trailer mass up to 750kg).
Product requires to be installed by specialized workshop - read here.
- Product's EAN code: 5907662621251
- Main control unit 1 pc
- Integrated wire harness (all-in-1-plug) 1 pc
- Signal harness for steering of PDC 1 pc
- Socket G7 1 pc
- Mounting set 1 set
- Screw set 1 set
- Connections diagram 1 pc
